    350 Kg / H Transparent Plastic Sheet Extrusion Line Double Vents Thermoforming

    APET / PETG / CPET/PLA Sheet Extrusion Making machine


    It’s one of the most advanced production lines with matured technology and stability in China. Compared with other same kind equipment, it’s over 30% higher in overall efficiency. The line is also suitable for PS, PP, PE sheet production.


    No Crystallizer &Dryer, Double Vents

    Free of crystallization drying system, the new designed line can greatly reduce cost of production.


    Machine Parts


    1. PET Non-crystallization extruding system :The newest screw thread unit, low power consumption, high output, is suitable for PET sheet extruding.

    2. Three roller calender: The high-precision three roller calender forming system, with servo control, hydraulic compress structure, is cuitable for the stable extrusion of sheet thickness at 0.15mm.

    3. Precision die system:Can choose the self-regulation die to realize the change between extrusion mode and casting mode, is suitable for the sheet with different thickness.


    4. Automatic rolling & cutting device:Easy to adjust, cuting straightness is high. Thickness:0.8-10mm,width:800-2000mm

    SPECIFICATIONS FOR Pet/PETG/Petc Precision Sheet Making Machine
    ModelSJ120-GF1200 high exfficientGP-75/40-GF1000 Non crystalline
    Extruder ModelSJ120/35 single screwGP75/40 parallel double screw
    Main motor power110KW132KW
    Products thickness0.15-1.5mm0.15-1.5mm
    Capacity500kg/h600kg/h

    PAR T1 THIS LINE CONSISTS OF (COMPULSORY)
    1Automatic vacuum feeding machine1 set
    2High efficiency single screw extruder (65/33, 75/33,90/33,120/33)1 set
    3Hydraulic exchanging unit1 set
    4Melting gear pump1 set
    5T-type /hanger type die head (JC-Times brand)1 set
    6Three Roller Calendars (alloy steel material )1 set
    7Rollers thermoforming machine1 set
    8Cooling frame and edge cutting unit1 set
    9Haul off machine1 set
    10Plastic cutting machine-guillotine1 set
    11Twin position sheet winder1 set
    12Stacker1 set
    13Electrical cabinet (ABB,Omron, RKC,Schneider, Siemens etc)
    14Spare parts1 set
    PART 2 ACCESSORY MACHINE PARTS (OPTIONAL)
    1Air compressor1 set
    2Industrial water chiller1 set
    PART 3 SHEET SPECIFICATIONS
    1Sheet width600-800mm
    2Sheet thickness0.2-2mm
    3TypePet single layer/mono layer sheets
    4Raw material1. Can be virgin plastic pet material
    2. Can be recyclable material, like PET Bottle Flakes
    PART 4 SHEET APPLICATIONS
    1Packing, printing, stationery, art works etc.
    2Main Products: Gift/ad/file bag/lamp cover/food packaging
