Double Shaft Plastic Shredder Machine , SN - S3980 Foam Shredder Machine

    Buy cheap Double Shaft Plastic Shredder Machine , SN - S3980 Foam Shredder Machine from wholesalers

    Buy cheap Double Shaft Plastic Shredder Machine , SN - S3980 Foam Shredder Machine from wholesalers
    • Buy cheap Double Shaft Plastic Shredder Machine , SN - S3980 Foam Shredder Machine from wholesalers

    Double Shaft Plastic Shredder Machine , SN - S3980 Foam Shredder Machine

    Ask Lasest Price
    Brand Name : YUREFON
    Model Number : SN-S3980
    Certification : CE SGS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 200SETS/YEAR
    Delivery Time : 40DAYS
    • Product Details
    • Company Profile

    Double Shaft Plastic Shredder Machine , SN - S3980 Foam Shredder Machine

    Cardboard Carton Paper Scrap Copper Wire Foam Plastic double Shaft Shredder for sale


    Descriprion of Plastic double Shaft Shredder:

    Two Shaft Shredders operate at low speed with high torque to minimized noise
    and power consumption, whilst achieving high throughput rates.

    This range of machines are particularly well suited to the size reduction of bulky or
    voluminous materials which can include contamination such as metals or stones.

    Manufactured from heat treated 42CrMo high grade alloy, the blades present excellent
    wear and shock resistant properties.


    This double shaft shredder/shredding machine can shred various plastic, such as bulk materials, metal, wood, plastic bottle, basket, boxes, carboard, pallets, pipe, plate, sheet, tire, big roll film,and some heavy duty city weste which are difficult to be shredded by single shaft shredder.
    Our company has many years experience in manufacturing the plastic shredder machine, we can produce this double shaft shredder machine according to your requirpment.

    Characteristics of Plastic double Shaft Shredder:
    1. The frame is combinational structures, made from precision machined extra-thick sheet, slewing axis is forced, Lange-angle, hexagonal prism, the hopper is large-caliber, and substantial, so good-sized material is practicable.
    2. Revolving knife is designed and processed particular in thickness, shape, arrange order and so on.
    3. PLC control system, forward and reverse operate and stop automatically can protect the machine when the materials is too big and much. Operate safely, low-speed running, low noise, little dust.
    4. The knife is made from special alloy steel, sturdy and durable.


    Main parameter for Double shaft shredder:

    Shredder Model

    SN-D800

    SN-D1000

    SN-D1200

    SN-D1600

    Dimension L/W/H(mm)

    3200×1250×2350

    3500×1250×2400

    3750×1250×2450

    4200×1650×2800

    Cutting Chamber C/D(mm)

    860×950

    1060×1100

    1260×1030

    1660×1100

    Height of discharge port E(mm)

    500

    500

    500

    560

    Cylinder Stroke(mm)

    900

    900

    900

    900

    Rotor Diameter(mm)

    φ350.3*2

    φ400.3*2

    φ400.3*2

    φ500.3*2

    Main Shaft Speed (r/min)

    74

    74

    74

    74

    Screen Mesh(mm)

    φ40

    φ40

    φ40

    φ40

    Rotor-knives(PCS)

    78

    128

    152

    200

    Stator-knives(PCS)

    3

    6

    6

    6

    Main Motor Power(KW)

    22*2

    37*2

    45*2

    55*2

    Hydraulic Motor Power(KW)

    2.2

    2.2

    5.5

    5.5

    Weight(KG)

    4000

    6500

    7500

    8500
